適用范圍Scope of application

精細化工產品、添加劑、醫藥原料等超細粉料以及有高精度包裝要求的粉未。

Fine chemical products,additives, pharmaceutical raw materials and other ultrafine powder and powder with high precision packaging requirements

功能特點Funcational characteristics

1、氣動夾裝置和拖架裝在重量傳感器上根據預先設定的重量進行快速和慢速充填，高反應速度的稱重系統,保證高包裝精度。

Pneumatic clamp device and trailer mounted on the weight sensor, according to the pre-set weight for fast and slow filling, high reaction speed weighing system, to ensure high packaging accuracy.

2、伺服電機帶動托盤升降，升降速度可任意設定，充填時基本上無粉塵揚出污染環境。

Servo motor drive pallet lifting, lifting speed can be arbitrarily set, basically no dust when filling environmental pollution.

3、何服馬達及司服驅動控制螺桿，性能穩定、精度高。

He Fu motor and service drive control screw,stable performance, high precision.

4、PLC控制、觸摸屏人機界面顯示，操作簡便。

PLC control,touch screen man-machine interface display, easy to operate.

5、全不銹鋼結構;組合式成開啟式料箱,清洗十分方便

All stainless steel structure；Combined into open type material box, cleaning is very convenient.

6、充填頭配有手輪調整高度,輕松實現多種規格包裝。

The filling head is equipped with a hand wheel to adjust the height, easily realizing a variety of specifications packaging.

7、固定式螺桿安裝結構，充填時不會影響物料性質。

Fixed screw installation structure, filling will not affect the material properties.

技術參數Technical parameters

1、型號：PUD-25VS

Model：PUD-25VS

2、包裝范圍：1-25

Packing range(kg)：1-25

3、包裝速度(bag/h)：1.5-3

Packing speed(bag/h)：1.5-3

4、稱重精度：1-20kg,≤±0.1%~±0.2%,>20kg,≤±0.05-0.1%

Weighing precision：1-20kg,≤±0.1%~±0.2%,>20kg,≤±0.05-0.1%

5、電源：3P AC208-415V  50/60Hz

Power supply：3P AC208-415V  50/60Hz

6、壓縮空氣：6kg/cm2  0.lm3/min

Compressed air：6kg/cm2  0.lm3/min

7、整機重量：500kg

Overall weight：500kg

8、整機體積：1125x975x3230mm

Overall volume：1125x975x3230mm

9、料箱容積：100L

Bin volume：100L

10、整機功率：3.62KW

Overall power：3.62KW

-取決于包裝物料的具體特性和包裝規格。

Depend on the specific characteristics of packaging materials and packaging specifications.
